Pinnacle Photon in Grey

A mountain bike for trails and cross-country riding. With a relatively short 120mm travel, the Photon is agile and efficient on the climbs, whilst the modern geometry and full-suspension set up are there to keep things under control on the descents.

For the rider looking for the added traction, control and comfort that a full-susser brings. Ideal for someone who is riding cross country or single-track trails. Maybe this is a first full-suspension MTB, stepping up from hardtail mountain bikes. All at a super affordable price.

Key Features

-
• Alloy 120mm full-suspension frame, internal cable routing, dropper post routing

-
• Suntour XCM32 120mm travel fork with 32mm stanchions

-
• Suntour Raidon Lo-Air shock

-
• Shimano Cues 1x9 speed drivetrain

-
• WTB Trailboss 29x2.25 tires

-

Specifications

Frameset

-
• Frame: 6061 Alloy full-suspension, internal cable routing, dropper post routing

-
• Fork: Suntour XCM32, 120mm travel, 32mm stanchion, coil, pre-load, lockout

-
• Rear Shock: Suntour Raidon Lo Air, 190x15mm.

-

Wheels

-
• Rims: Alloy, 29, 32h, presta valve.

-
• Hubs: Joytec, D761/2, alloy, disc brake, 6 bolt, 32h, F: 100mm QR, R: 135mm QR

-
• Tyres: WTB Trail Boss 29x2.25, Comp, wire bead, DNA Compound.

-

Drivetrain

-
• Crankset: Prowheel Charm, FD04S, 32t, narrow wide chainring.

-
• Shifters: Shimano Cues, U4000, 9 speed.

-
• Rear Derailleur: Shimano Cues, U4000, 9 speed shadow.

-
• Front Derailleur: N/A

-
• Chain: KMC Xglide.

-
• Cassette: Shimano LG300, 9 speed, 11-46t, 11-13-15-17-20-23-28-36-46t.

-
• Bottom Bracket: Prowheel.

-

Components

-
• Handlebar: Alloy 31.8mm, 20mm rise, 6 deg, S: 760mm, M-L: 780mm.

-
• Stem: Alloy, 31.8mm, 3 deg, 45mm.

-
• Grips: Velo, black, 130mm.

-
• Brakes: Tektro HD-M280, hydraulic disc brake, F: 180mm, R: 160mm rotors.

-
• Saddle: Black, steel rail.

-
• Seatpost: Alloy 31.6mm, 350mm.

-

Photon
