Substance Sword

Vitus Substance Sword in Green

€1,597.77

Size View Size Guide

SIZE	CHEST (ins)	CHEST (cms)	WAIST (ins)	WAIST (cms)
XS	34 - 36	86 - 91	28 - 30	70 - 75
S	36 - 38	91 - 96	30 - 32	75 - 80
M	38 - 40	96 - 101	32 - 34	80 - 85
L	42 - 44	106 - 111	34 - 36	85 - 90
XL	44 - 48	111 - 121	36 - 38	90 - 95
XXL	50 - 52	127 - 132	38 - 40	95 - 100
XXXL	54 - 56	137 - 142	40 - 42	100 - 105

UK	US	Europe
6	7	39
6.5	7.5	40
7	8	41
7.5	8.5	41.5
8	9	42
8.5	9.5	42.5
9	10	43
9.5	10.5	43.5
10	11	44
10.5	11.5	45
11	12	46
11.5	12.5	46.5
12	13	47
12.5	13.5	47.5
13	14	48

SIZE	UK SIZE	BUST (ins)	WAIST (ins)	INSIDE LEG (ins)
6	XXS	30	24	27 -28
8	XS	32	26	28
10	S	33	28	28 - 29
12	M	35	30	29
14	L	37	32	29 -30
16	XL	39	34	30 - 31

UK	US	Europe
3	5.5	36
3.5	6	36.5
4	6.5	37
4.5	7	37.5
5	7.5	38
5.5	8	38.5
6	8.5	39
6.5	9	40
7	9.5	41
7.5	10	41.5
8	10.5	42
8.5	11	42.5
9	11.5	43
9.5	12	43.5
10	12.5	44

Order by age	Height	Chest	Waist	Inside leg	Collar circ	Size
yrs	cms	ins	ins	ins	ins
3/4	104	21	20.5	19	11
4/5	110	22	21	20	12	XS
5/6	116	23	22	21	12	XS
6/7	122	24	22.5	21.5	12.5	S
7/8	128	25	23	22	12.5	S
8/9	134	26	23.5	23	13	M
9/10	140	27	2	23.5	13	M
10/11	146	28	25	24.5	13.5	M
11/12	152	29	26	25	13.5	L
12/13	158	30	27	26	14	L
13/14	164	32	28	27	14.5	XL
14/15	170	34	29	28	15	XL

Order by age	Height	Chest	Waist	Inside leg
yrs	cms	ins	ins	ins
5	110	22	20.5	19.5
6	116	23	21	21
7	122	23.5	21.5	22
8	128	24.5	21.5	23.5
9	134	25.5	22.5	25
10	140	27	23	26.5
11	146	29	24	28
12	152	31	25	29
13	158	32	25.5	29.5
14	164	33.5	26.5	30.5
15	170	35	27	31.5
16	176	36.5	28	31.5

UK	US	Europe
2.5	3.5	35
3	4	36
3.5	4.5	36.5
4	5	37
4.5	6	37.5
5	6.5	38
5.5	6.5	38.5
6	7	39

S M L XL

Product Description
Product Code: FR3139878
On road, off road, the choice is yours. A bike designed to be ridden wherever you want to go. Could be used for a weekend day spin around local trails, paths and roads. Or loaded up with racks and luggage for bike-packing adventures. Or equally at home on a mixed terrain daily commute.

-
The Substance is for a rider who wants their bike to go wherever they want to go. For someone who doesn’t want lots of different bikes for lots of different types of ride, someone looking for 1 bike that can do it all, trails, paths, roads, daily commute. The substance is happy with it all.

-

-

-
Key Features
- 6061 Alloy frame, thru-axle, universal derailleur hanger, internal cable routing, dropper post routing, rack and mudguard mounts.
- Microshift Sword 2x9 speed shifting.
- WTB ST i23 rims
- WTB 700x37c TCS DNA light compound, tubeless tires.
- Tektro MD C-550 mechanical flat mount disc brakes.
-

-
Specifications
Frameset
- Frame: 6061 Alloy, UDH, internal routing, flat mount. rack mounts. Dropper routing.
- Fork: UD Carbon, carbon steerer, thru-axle, mudguard and rack mounts.
- Rear Shock: N/A
-
Wheels
- Rims: WTB 700c STi23 TCS2.0, 32h, 23mm internal.
- Hubs: Solon DH510, 32h, thru-axle, 12x100(f) 12x142(r), 6-bolt, sealed bearing.
- Tyres: WTB Riddler TCS Light, 700x37c, foldable, tubeless, dual DNA compound.
-
Drivetrain
- Crankset: Prowheel RPZ-C701X, 46x29.
- Shifters: Microshift Sword SB-G7900(20) 2x9 speed, dual control.
- Rear Derailleur: Microshift Sword RD-G7920L, 9-speed.
- Front Derailleur: Microshift Sword FD-G7920, down pull, down swing.
- Chain: KMC X9, 9-speed, 120 link.
- Cassette: Microshift CS-H093, 9-speed, 11-38t, 11-13-15-18-21-24-28-32-38.
- Bottom Bracket: FSA BB-7420ST, 68mm.
-
Components
- Handlebar: Alloy 31.8mm, 124mm drop, 80mm reach. S 440mm width, M-XL 460mm width
- Stem: Alloy 31.8mm, 7-degree, S 90mm, M-XL 100mm.
- Grips: Velo VLT-001
- Brakes: Tektro MD C-550, mechanical flat mount disc, 160mm rotor, 6 bolt.
- Saddle: Black, steel rail.
- Seatpost: Alloy 30.9x350mm. 15mm offset.
-

-
Substance
S M L XL
Rider Height (cm) 168 - 175 173 - 180 178 - 186 183 - 191
Inside Leg (cm) 71 - 78 76 - 84 78 - 86 84 - 91
-

	S	M	L	XL
Rider Height (cm)	168 - 175	173 - 180	178 - 186	183 - 191
Inside Leg (cm)	71 - 78	76 - 84	78 - 86	84 - 91
