Vitus Substance Grx in Orange

£1,199.00 £1,799.00 Save £600.00 (33%)

Size View Size Guide

SIZE	CHEST (ins)	CHEST (cms)	WAIST (ins)	WAIST (cms)
XS	34 - 36	86 - 91	28 - 30	70 - 75
S	36 - 38	91 - 96	30 - 32	75 - 80
M	38 - 40	96 - 101	32 - 34	80 - 85
L	42 - 44	106 - 111	34 - 36	85 - 90
XL	44 - 48	111 - 121	36 - 38	90 - 95
XXL	50 - 52	127 - 132	38 - 40	95 - 100
XXXL	54 - 56	137 - 142	40 - 42	100 - 105

UK	US	Europe
6	7	39
6.5	7.5	40
7	8	41
7.5	8.5	41.5
8	9	42
8.5	9.5	42.5
9	10	43
9.5	10.5	43.5
10	11	44
10.5	11.5	45
11	12	46
11.5	12.5	46.5
12	13	47
12.5	13.5	47.5
13	14	48

SIZE	UK SIZE	BUST (ins)	WAIST (ins)	INSIDE LEG (ins)
6	XXS	30	24	27 -28
8	XS	32	26	28
10	S	33	28	28 - 29
12	M	35	30	29
14	L	37	32	29 -30
16	XL	39	34	30 - 31

UK	US	Europe
3	5.5	36
3.5	6	36.5
4	6.5	37
4.5	7	37.5
5	7.5	38
5.5	8	38.5
6	8.5	39
6.5	9	40
7	9.5	41
7.5	10	41.5
8	10.5	42
8.5	11	42.5
9	11.5	43
9.5	12	43.5
10	12.5	44

Order by age	Height	Chest	Waist	Inside leg	Collar circ	Size
yrs	cms	ins	ins	ins	ins
3/4	104	21	20.5	19	11
4/5	110	22	21	20	12	XS
5/6	116	23	22	21	12	XS
6/7	122	24	22.5	21.5	12.5	S
7/8	128	25	23	22	12.5	S
8/9	134	26	23.5	23	13	M
9/10	140	27	2	23.5	13	M
10/11	146	28	25	24.5	13.5	M
11/12	152	29	26	25	13.5	L
12/13	158	30	27	26	14	L
13/14	164	32	28	27	14.5	XL
14/15	170	34	29	28	15	XL

Order by age	Height	Chest	Waist	Inside leg
yrs	cms	ins	ins	ins
5	110	22	20.5	19.5
6	116	23	21	21
7	122	23.5	21.5	22
8	128	24.5	21.5	23.5
9	134	25.5	22.5	25
10	140	27	23	26.5
11	146	29	24	28
12	152	31	25	29
13	158	32	25.5	29.5
14	164	33.5	26.5	30.5
15	170	35	27	31.5
16	176	36.5	28	31.5

UK	US	Europe
2.5	3.5	35
3	4	36
3.5	4.5	36.5
4	5	37
4.5	6	37.5
5	6.5	38
5.5	6.5	38.5
6	7	39

S M L XL

Product Description
Product Code: FR3139879
On road, off road, the choice is yours. A bike designed to be ridden wherever you want to go. Uphill, downhill, fast on the flats. No problem. With a great range of gears from the Shimano GRX 2x11 speed. And great stopping power from the Shimano GRX brakes. Great for gravel days out, loaded up bike-packing adventures or mixed terrain commutes.

-
Somone looking for the best value hydraulic brake gravel bike in the market. A rider who wants their bike to go wherever they want to go. Someone one who wants a great range of gears from the 2x11 speed Shimano GRX drivetrain and powerful GRX hydraulic disc brakes.

-

-

-
Key Features
- 6061 Alloy frame, thru-axle, universal derailleur hanger, internal cable routing, dropper post routing, rack and mudguard mounts.
- Shimano GRX 2x11 gears.
- Shimano GRX hydraulic disc brakes
- WTB ST i23 rims
- WTB 700x37c TCS DNA light compound, tubeless tires.
-

-
Specifications
Frameset
- Frame: 6061 Alloy, UDH, internal routing, flat mount. rack mounts. Dropper routing.
- Fork: UD Carbon, carbon steerer, thru-axle, mudguard and rack mounts.
- Rear Shock: N/A
-
Wheels
- Rims: WTB 700c STi23 TCS2.0, 32h, 23mm internal.
- Hubs: Novotech D791SB, 32h, thru-axle, 12x100(f) 12x142(r), 6-bolt.
- Tyres: WTB Riddler TCS Light, 700x37c, foldable, tubeless, dual DNA compound.
-
Drivetrain
- Crankset: FSA Omega 46x36t, megaexo.
- Shifters: Shimano GRX 2x11 speed.
- Rear Derailleur: Shimano GRX RD-RX810 GRX, shadow RD+.
- Front Derailleur: Shimano GRX FD-RX810 GRX.
- Chain: KMC X11, 11-speed, 120 link.
- Cassette: Shimano CH-HG900-11, 11-34t, 11-13-15-17-19-21-23-25-27-30-34.
- Bottom Bracket: FSA Omega, BSA .
-
Components
- Handlebar: Alloy flared 16-deg, 128mm drop, 77mm reach. S 440mm w, M-XL 460mm w
- Stem: Alloy 31.8mm, 7-degree, S 90mm, M-XL 100mm.
- Grips: Velo VLT-001
- Brakes: Shimano GRX, flat mount.
- Saddle: Black, steel rail.
- Seatpost: Alloy 30.9x350mm. 15mm offset.
-

-
Substance
S M L XL
Rider Height (cm) 168 - 175 173 - 180 178 - 186 183 - 191
Inside Leg (cm) 71 - 78 76 - 84 78 - 86 84 - 91
-

	S	M	L	XL
Rider Height (cm)	168 - 175	173 - 180	178 - 186	183 - 191
Inside Leg (cm)	71 - 78	76 - 84	78 - 86	84 - 91
