Brompton Electric P Line 4 Speed High Bar in White

About the Brompton Electric P Line 4 Speed – Mid Handlebar with Rack

Lightweight. Electric made easy. The most compact folding e-bike, made even lighter. With a hand built titanium and steel frame and best-in-class componentry.

Get ready for next-level freedom with the Electric P Line folding bike. Lighter. Faster. Even more portable. This compact e-bike performs folded and unfolded, indoors and out. The ultra-light titanium rear frame and forks, design innovations, and smart electric system take your journeys to a whole new level.

The lightweight folding bike with a superlight compact 4-speed gear system fine-tuned for city riding.

Key Features

-
• Supercharge your day with the custom-made electric system developed with Williams Advanced Engineering. The compact250-W hub motor does the hard work for you. Hop on and choose from three levels of Smart Pedal Assist. Start your ride. Feel the torque. The fine-tuned sensor in the bottom bracket knows exactly when to start (smoothly) and ease off. Breeze through the city at speeds of up to 25 km/h (15 mph). Go and explore up to 70-kilometres (45-miles).

-

Specifications

Frameset

-
• Frame: Precision drawn heat-treated steel tubing with hand brazing and selected auto-brazed joints

-
• Rear Frame: Superlight Advance rear frame made from Titanium with a replaceable hanger, redesigned suspension block

-
• Fork: Reinforced steel brazed fork

-

Wheels

-
• Front Wheel: 250W Brushless DC motor providing assistance up to 25 km/h
  -

-
• Rear Wheel: Single wall alloy rim, 28 spokes laced to a 4 speed rear hub

-
• Rims: Alloy

-
• Mudguards: Curved profile with updated mudguard flaps

-
• Roller Frame: Rear Roller Frame for added folded stability and enhanced portability through 4 roller wheels. Allows easy rolling of bike whilst folded.

-

Drivetrain

-
• Pedals: Quick Release other than Emerald Lacquer, Storm Grey and Midnight Black feature Brompton Folding left hand and non-folding right-hand pedals

-
• Crank: (6061) forged aluminium crank with 54T chainring and integrated chainguard

-
• Rear Derailleur: Patent-pending direct mount 4-speed derailleur

-
• Shifters: Brompton 4-speed trigger shifter

-
• Chain Tensioner: Advance chain tensioner with replaceable hanger mounting

-
• Bottom Bracket: Integrated sealed bearing BB with cadence and torque sensor

-

Components

-
• Handlebar: High handlebar, triple butted (6061) aluminium with shot-peened finish

-
• Grips: Superlight lock-on grips with precision ground lightweight foam adhered to ultrathin engineered core weighing just 42g per pair

-
• Headset: Superlight headset

-
• Brakes: Brompton Dual Pivot Calipers

-
• Brake Levers: Brompton levers

-
• Saddle: Superlight

-
• Seatpost: Chromoly steel tube, centreless ground, chrome plated for hardness, delivered in a standard length, suitable for maximum inside leg 33 inches / 84 cm

-

Electrics

-
• Lighting: 40 Lux Busch & Müller AVY LED front lamp and rear lamp powered by the main battery

-
• Battery: 300Wh 36V with LED display. Range 20-45 miles (30-70km). 5V 1.5A USB port to charge portable devices. 4-hour full charge using included 2A charger

-
